Fan Model |
CC8015H12D |
|
Dimension |
80*80*15 MM |
|
Voltage |
12V(10.8-13.2V) |
|
Power consumption |
DUTY CYCLE=100% 3.84W DUTY CYCLE=0% 0.60W |
|
Rated current |
DUTY CYCLE=100% 0.32±0.02A DUTY CYCLE=0% 0.05A±0.02A |
|
Speed |
DUTY CYCLE=100% 4000±10%RPM DUTY CYCLE=0% 1500±200RPM At 25℃,After 3~5 minutes rotating (Fan alone) |
|
Noise |
DUTY CYCLE=100% 42dBA (max) |
|
Bearing |
2-Ball Bearing UL1007 28# L=200±10MM |
|
Connector |
2510-4PIN |
