Fan Model |
CC14025L12 |
|
|
Dimension |
120x120x25mm |
|
|
Voltage |
12V |
|
|
Power consumption |
1.8W |
DUTY CYCLE=100% 4.08W DUTY CYCLE=0% 1.8W |
|
Rated current |
0.15A |
DUTY CYCLE=100% 0.19±0.02A DUTY CYCLE=0% 0.12±0.02A |
|
Speed |
1,000±10%RPM |
DUTY CYCLE=100% 1400±140RPM DUTY CYCLE=0% 1000±100RPM |
|
Noise |
24 dB-A |
DUTY CYCLE=100% 31dBA(max) |
|
Bearing |
Sleeve bearing and Hydraulic bearing for optional |
|
|
Connector |
2510-3P + 4P |
2510-4P |
