Fan Model |
CF120A |
CF120A PWM |
|
Dimension |
120x120x25mm |
|
|
Voltage |
12V(10.8-13.2V) |
|
|
Power consumption |
2.40W |
DUTY CYCLE=100% 3.00W DUTY CYCLE=0% 1.08W |
|
Rated current |
0.2A |
DUTY CYCLE=100% 0.25±0.02A DUTY CYCLE=0% 0.09±0.02A |
|
Speed |
1,000±10%RPM |
DUTY CYCLE=100% 1500±150RPM DUTY CYCLE=0% 600±150RPM |
|
Noise |
21 dB-A |
DUTY CYCLE=100% 30dBA(max) |
|
Bearing |
Sleeve bearing / bearing ball |
|
|
Connector |
2510-3P + 4P |
2510-4P |
