ATX300W-12CM Red fan;
Male socket+I/O+transfer switch;
Silver fan ne;
Product features
Name ATX-300W
Model ATX 12V V2.3-300W
Rated power 300W
Max power 380W
Connector 20+4P(sleeve),P8(4+4),PCI-E6P,SATA,HDD+2SATA,2HDD+FDD
Fan 12CM Red fan
Safety certificates CB、CE、CCC、RoHS
Description
1. Complying with INTEL ATX 12V V2.3, strengthened +12V output current provides Prescott core P4 platform a strong impetus.
2. Using S-ATA connector, compatible effectively with SATA high-speed hard disk.
3. Using 20+4PIN output connector, no need to convert, directly support to use 24pin M/B and meet different motherboards’ standard.
4. Build-in LC multiple filter circuit to filter ripple, noise and inrush current.
5. Supporting Intel, AMD, VIA and other PC configuration.
Protection OVP, OLP, OCP, UVP, SCP
High voltage Voltage 1500V AC, Time 2-3 Sec, Leakage current 10Ma Max.
